A.

Feature

- Built-in 2 Channel with Source and Measure Unit

- Built-in 1 Channel with Preamp

- Independent 0.1fA measurement resolution

- Support both pulsed I-V testing for devices with self-heating issues

- General purpose pulsing and general purpose pulsing and pulse measurement

- Pulse I-V software included provides both cable

- Compensation and load-line compensation

- Self-contained PC provides fast test setup, powerful data analysis

- Graphing and printing, and on board mass storage of test results

- Built-in stress/measure, looping, and data analysis for point-and-click, reliability testing

B.

Specification

- Current Measurement Range: ±100nA to ±100mA

- Minimum Current Measurement Resolution: ±0.1fA

- Minimum Current Measurement Accuracy: ±10fA

- Voltage Measurement Range: ±200mV to ±200V

- Minimum Voltage Measurement Resolution: ±1uV
